衬氟对夹蝶阀产品用途
衬氟对夹蝶阀用于各种不同类型工业管道中液体和气体（包括蒸 气）的输送，特别是具有严重腐蚀性介质的使用场合，如：硫酸、氢氟酸、磷酸、氯气、强碱、王水等具有强腐蚀性的介质。
衬氟对夹蝶阀产品参数：
|
DN |
NPS |
L |
D |
D1 |
D2 |
F |
B |
N-?D |
W |
D0 |
H |
WT(kg) |
|
PN0.6MPa |
||||||||||||
|
40 |
1 1/2 |
106 |
130 |
100 |
80 |
3 |
16 |
4-?14 |
160 |
|
140 |
10 |
|
50 |
2 |
108 |
140 |
110 |
90 |
3 |
16 |
4-?14 |
200 |
|
160 |
12 |
|
65 |
2 1/2 |
112 |
160 |
130 |
110 |
3 |
16 |
4-?14 |
250 |
|
160 |
13 |
|
80 |
3 |
114 |
185 |
150 |
125 |
3 |
18 |
4-?18 |
250 |
|
170 |
14 |
|
100 |
4 |
127 |
205 |
170 |
145 |
3 |
18 |
4-?18 |
300 |
|
180 |
16 |
|
125 |
5 |
140 |
235 |
200 |
175 |
3 |
20 |
8-?18 |
300 |
|
275 |
18 |
|
150 |
6 |
140 |
260 |
225 |
200 |
3 |
20 |
8-?18 |
|
200 |
295 |
38 |
|
200 |
8 |
152 |
315 |
280 |
255 |
3 |
22 |
8-?18 |
|
200 |
320 |
74 |
|
250 |
10 |
250 |
370 |
335 |
310 |
3 |
24 |
12-?18 |
|
240 |
385 |
105 |
|
300 |
12 |
270 |
435 |
375 |
362 |
4 |
24 |
12-?23 |
|
240 |
390 |
142 |
|
350 |
14 |
290 |
485 |
445 |
412 |
4 |
26 |
12-?23 |
|
240 |
460 |
179 |
|
400 |
16 |
310 |
535 |
495 |
462 |
4 |
28 |
16-?23 |
|
280 |
510 |
220 |
|
450 |
18 |
330 |
590 |
550 |
518 |
4 |
28 |
16-?23 |
|
280 |
540 |
268 |
|
500 |
20 |
350 |
640 |
600 |
568 |
4 |
30 |
16-?23 |
|
320 |
570 |
378 |
|
600 |
24 |
390 |
755 |
705 |
670 |
5 |
30 |
20-?25 |
|
320 |
660 |
608 |
|
700 |
28 |
430 |
860 |
810 |
775 |
5 |
32 |
24-?25 |
|
360 |
710 |
1050 |
|
800 |
32 |
470 |
975 |
920 |
880 |
5 |
34 |
24-?30 |
|
360 |
780 |
1320 |
|
900 |
36 |
510 |
1075 |
1020 |
980 |
5 |
36 |
24-?30 |
|
380 |
885 |
1795 |
|
1000 |
40 |
550 |
1175 |
1120 |
1080 |
5 |
36 |
28-?30 |
|
400 |
990 |
|
|
PN1.0MPa |
||||||||||||
|
40 |
1 1/2 |
106 |
145 |
110 |
85 |
3 |
18 |
4-?18 |
160 |
|
140 |
10 |
|
50 |
2 |
108 |
160 |
125 |
100 |
3 |
20 |
4-?18 |
200 |
|
160 |
12 |
|
65 |
2 1/2 |
112 |
180 |
145 |
120 |
3 |
20 |
4-?18 |
250 |
|
165 |
14 |
|
80 |
3 |
114 |
195 |
160 |
135 |
3 |
22 |
4-?18 |
250 |
|
170 |
16 |
|
100 |
4 |
127 |
215 |
180 |
155 |
3 |
22 |
8-?18 |
300 |
|
180 |
18 |
|
125 |
5 |
140 |
245 |
210 |
185 |
3 |
24 |
8-?18 |
300 |
|
275 |
20 |
|
150 |
6 |
140 |
280 |
240 |
210 |
3 |
24 |
8-?23 |
|
200 |
295 |
38 |
|
200 |
8 |
152 |
335 |
295 |
265 |
3 |
26 |
8-?23 |
|
200 |
320 |
74 |
|
250 |
10 |
250 |
390 |
350 |
320 |
3 |
28 |
12-?23 |
|
240 |
385 |
105 |
|
300 |
12 |
270 |
440 |
400 |
368 |
4 |
28 |
12-?23 |
|
240 |
390 |
142 |
|
350 |
14 |
290 |
500 |
460 |
428 |
4 |
30 |
16-?23 |
|
240 |
460 |
179 |
|
400 |
16 |
310 |
565 |
515 |
482 |
4 |
32 |
16-?25 |
|
280 |
510 |
220 |
|
450 |
18 |
330 |
615 |
565 |
532 |
4 |
32 |
20-?25 |
|
280 |
540 |
268 |
|
500 |
20 |
350 |
380 |
620 |
585 |
4 |
34 |
20-?25 |
|
320 |
570 |
378 |
|
600 |
24 |
390 |
780 |
725 |
685 |
5 |
36 |
20-?30 |
|
320 |
660 |
608 |
|
700 |
28 |
430 |
895 |
840 |
800 |
5 |
40 |
20-?30 |
|
360 |
710 |
1050 |
|
800 |
32 |
470 |
1010 |
950 |
905 |
5 |
44 |
24-?34 |
|
360 |
780 |
1320 |
|
900 |
36 |
510 |
1110 |
1050 |
1005 |
5 |
46 |
28-?34 |
|
380 |
885 |
1795 |
|
1000 |
40 |
550 |
1220 |
1160 |
1115 |
5 |
50 |
28-?34 |
|
400 |
990 |
1900 |
